High Precision Glass Cutting Line 220V Horizontal Glass Mirror Cutting Machine

Model Number : YTJ3826

Voltage : AC 220V 50-60Hz

MOQ : 1set

Delivery Time : 30 woring days

Xy Axis Travel : 1000mm*900mm

Brand Name : Foshan star

Structure : Horizontal

Packaging Details : protective fim

Payment Terms : L/C,T/T,Western Union

Price : $15000-$28000/set

Control Accuracy : +/- 0.02mm

Supply Ability : 20Set each month

Certification : CE

Glass Size : 3800*2600mm

Place of Origin : CHINA

Glass Thickness : 2~6mm

Contact Now

High Precision Glass Cutting Machine For Precise Glass Cutting

Product Description

YTJ3826 intelligent glass loading and cutting machine consists of two systems: loading and cutting machine and air-floating breaking table. It integrates automatic loading, automatic optimization layout, automatic labeling, automatic cutting, automatic transportation and air-floating breaking table, and realizes automatic operation of glass cutting process. The machine is equipped with power walking wheels, which can be controlled by remote control in the working area for easy shifting. The machine can realize straight and special-shaped cutting of glass, and is suitable for architectural glass, furniture glass, craft glass, decorative glass, cabinet glass, glass mirror, etc.

Product Features

High precision and efficiency

It can accurately control the position and angle of the cutting line, quickly complete a large number of cutting tasks, and ensure the consistency and stability of the cutting line.YTJ3826 intelligent glass loading and cutting machine consists of two systems: loading and cutting machine and air-floating breaking table. It integrates automatic loading, automatic optimization layout, automatic labeling, automatic cutting, automatic transportation and air-floating breaking table, and realizes automatic operation of glass cutting process. The machine is equipped with power walking wheels, which can be controlled by remote control in the working area for easy shifting. The machine can realize straight and special-shaped cutting of glass, and is suitable for architectural glass, furniture glass, craft glass, decorative glass, cabinet glass, glass mirror, etc.

Product Specifications

Item	3826 Model
Total floor space (including the breaking table, the height does not include the unfolded height of the breaking table)	Size: 570048601600mm
Cutting table dimensions	310048601630mm
Breaking table dimensions	38002600880mm (adjustable)
Processing glass size	MAX. 3660*2440mm
Countertop height	880±30mm (foot adjustable)
Loading Depth	About 700 mm
Power Requirements	Three fires and one ground wire 380V (special voltages should be communicated in advance)
Installed power	About 15kW
Compressed air	0.6-0.8Mpa, 0.6-0.8 Mpa exhaust volume 0.6-1m³/min
Glass thickness	3～18mm, Lower than 3mm or higher than 12mm (excluding 12mm) must be informed in advance
Cutting head speed	0-200M/min (can be set)
Cutting bridge speed	0-200M/min (can be set)
Cutting acceleration	≥8m/s²
Cutting knife holder	The cutter head can rotate 360 degrees (precisely cut straight lines and shapes)
Cutting accuracy	≤±0.3mm/s

Product Service
